ZTW Skyhawk 155A ESC with 10A SBEC

Details

Skyhawk 155A ESC with 10A SBEC from ZTW – ZTW4155211

This ZTW Skyhawk ESC is a premier quality brushless electronic speed control with an integrated switch-mode BEC; eliminating the need for a separate receiver battery, it conserves weight and simplifies wiring. Crafted with an aluminum heat sink body, it is lightweight and disperses heat efficiently. With a BEC specifically designed to support high-powered applications, you won’t encounter any unexpected power shutdowns, while it can also handle multiple servo operations seen on big airplanes and 3D helicopters. If you’re in search of a top-of-the-line, full-featured ESC at a great price, the Skyhawk is your best bet.

Features:

• Built-in cooling fan for efficient heat dissipation and reliable operation
• High-performance 32-bit M4 microprocessor running at 170MHz
• Data logging system such as temperature, voltage, current, and RPM
• SBEC Voltage Output 6.0, 7.4, and 8.4V
• High SBEC Current Output designed to meet your high current applications
• Power on protection, over-heat protection, low-voltage protection and lost-signal protection
• Super smooth and accurate throttle linearity
• Support for most motors, including high RPM motors
• Programmable motor timing
• Utilizes new MOSFET technology for low heat and high reliability
• Aluminum finned heat sink
• Programmable throttle input range
• ESC firmware and program settings can be updated via the Android or Apple mobile APP (bluetooth module sold separately)

Includes:

• ZTW Skyhawk 155A ESC with 10A SBEC
• Pre-installed EC5 Connector (power connector) and 4mm bullet (motor connector) for your convenience
• Instruction Manual

Optional:

• ZTW G2 LCD Programming Card – Click here for more info
• ZTW Bluetooth Programming Module – Click here for more info
